Trend Display – Y scale control

EasyBuilder Pro adds Y-scale feature in Trend Display object. The Y-scales can be shown or hidden, and the order or range of Y-scales can be changed dynamically on HMI.

Overview:

1. Display/Hide Y-scale of each channel, respectively.



2. Change the order of Y-scale of each channel.



3. Change the upper and lower limit of Y-scales.



Explore more

Demo project
