MT8053iE – The Most Compact HMI with Dual Ethernet Ports

by · Published · Updated

Product Introduction

Just as Ethernet gradually becomes a standard interface for PLC, the demand for data exchange with the upper layer devices (SCADA) over the network and integration with cloud services is also on the rise. Faced with these demands, Weintek has released models with dual Ethernet ports: MT8073iE(7”), MT8092XE(10”), and cMT Series, which has all received positive feedbacks. To provide users with a wider choice of screen sizes, the dual-Ethernet HMI now comes in 4.3”, the first in the product lineup being MT8053iE.

Adding new I/O ports into such small enclosure is always a challenge due to space constraints, but Weintek has pushed the boundary to make it possible. Based on the existing 4.3”MT8050iE model, this new generation model MT8053iE has the same cutout dimension as its predecessor. Furthermore, despite its tiny profile, it has successfully incorporated dual-Ethernet architecture, and users will be able to reap all the benefits dual-Ethernet architecture may offer.

Dual-Ethernet-port ensures that MT8053iE can be on two independent networks, whereby one port connects to the controller, and the other one connects to the host computer or is used for remote control (e.g.: built-in EasyAccess 2.0). Not only will the separation of networks effectively avoid the possibility of network interference and congestion, but it will also greatly improve the reliability and stability of data transfer, leaving out security concerns.



MT8053iE Features

  • High Performance
    32-bit RISC 600MHz CPU and 16.7M colors display.
  • Rich I/O
    Dual-Ethernet, USB Host 2.0, Serial Ports COM1: RS-232/RS-4852W/4W COM3: RS-485 2W.
  • High Reliability
    Industrial level protections: PCB coating and power isolation
  • Wide Input Voltage Range
    10.5~28VDC wide voltage range input for installation in varied power conditions.
  • Powerful Connectivity
    Supports more than 300 drivers, most of which are for major brands of PLCs and controllers.
  • Remote Access Service, EasyAccess 2.0
    The EasyAccess 2.0 license is included; therefore, activation using an activation card is not necessary.
  • IIoT Protocol Support
    Supports MQTT and MODBUS TCP/IP Gateway, making it convenient to access data for upper layer devices.



Applicable software version: EasyBuilder Pro V6.02.01 or later (download)
